300 watt 24 volt solar panel is a cost-effective way of generating electricity for both the residential and industrial sectors. It’s a high efficiency solar panel, suitable to power small to large size load. The panel absorb sunlight and convert it into solar power with 17% to 21% efficiency.

An important metric to consider when comparing solar panel options is the power rating of a panel, called wattage. A 300 watt is close to the average wattage of a solar panel available today and is suitable for all types of solar projects.



Particulars	Description
Rated power	300 W
Open circuit voltage	44.5 V
Max. power voltage	35.5 V
Short circuit current	8.65 A
Max. power current	8.22 A
Module dimension	1968 x 987 x 40mm
Operating temperature	-40 C to 85 c
Module efficiency (%)	>19%
Max. system voltage	1000
Series fuse rating	15
Junction box	IP 65 / IP 67
Output cables	4mm², min. 900mm length
Connectors	MC4 Compatible
Protection	SCHOTTKY BYPASS DIODES
Cell layout	10 x 6
Frame	Anodized aluminum
Weight	22kg
No. of Solar Cells	72 (156 x 156 mm)
